Main features of the machine tool:

★ The casting material of the bed is a unique secret formula material, which has been specially treated to eliminate internal stress, reduce bed deformation, and ensure the long-lasting accuracy of the machine tool.

★ The grinding wheel spindle adopts a double support structure, with two sets of five piece dynamic pressure bearings. The spindle surface is made of ceramic material, which has good rigidity and minimal wear.

★ The guide wheel spindle adopts a double support structure, and the spindle bearing is a high-precision rolling bearing with high rotation accuracy and easy maintenance.

★ The main feed is the guide wheel frame feed, using double V-shaped rolling guide rails, and the feed method is servo motor+reduction mechanism+ball screw, which can achieve micro feed.

★ The feed and profiling of the grinding wheel dresser are based on rolling rails, and the reciprocating is based on dovetail rails. The feed uses a servo motor+ball screw, and the reciprocating uses a reduction motor+ball screw, ensuring accurate dressing compensation.

★ The feed of the guide wheel trimmer is a simplified manual feed, which is modeled as a rolling guide rail. It uses a reduction motor, ball screw, and dovetail guide rail for reciprocating movement.

★ The machine tool adopts a PLC control system and is equipped with a touch screen, with a friendly human-machine interface.
